CEV/NA,CEF/NA系列船用电缆参数
0.6/1kV
乙丙橡胶绝缘电力电缆
EPR insulated shipboard power calbe
CEV/NA
CEV80/NA
CEV90/NA
CEV82/NA
CEV92/NA
CEF/NA
CEF80/NA
CEF90/NA
CEF82/NA
CEF92/NA
用途 Application
船用电力电缆可用于河海各种船舶及海上石油平台等水 上建筑的电力照明和一般控制装置之用。对冶金、化工 、电力等工矿企业亦同样适用。
The cable is intended for power lighting and control system of shipboard and off-shore building such as oil platform. It is also available to metallurgical industy, chemical works, power plant and corporation mining
etc
结构 Construction
执行标准 Standards applied
IEC 60092-353 IEC 60228 Class2 IEC 60092-351 IEC 60092-359 IEC 60331 IEC 60332-3-22 | – 设计 – 导体 – 绝缘 – 护套 – 耐火 – 阻燃 | Design Conductor Insulation Sheath Fire Resistant Flame Retardant |
组分 Components | 代号 Code | 材料/描述 Material/Description |
系列代号 Series code | C | 船用电力电缆 Shipboard power cable |
导体 Conductor | 绞合镀锡退火铜， IEC 60228 Class 2 Stranded tinned annealed copper (STC), IEC 60228 Class 2 | |
绝缘 Insulation | E | 耐火云母带+乙丙橡胶 Mica glass tape + EPR, IEC 60092-351 |
内护套 Inner sheath | F | 氯丁橡胶 PCP |
V | 聚氯乙烯 PVC | |
铠装 Armor | 8 | 镀锡铜丝编织 Tinned copper wire braid (TCWB) |
9 | 镀锌钢丝编织 Galvanized steel wire braided (GSWB) | |
外护套 Outer sheath | 0 | 无外护套 Without outer sheath |
2 | 聚氯乙烯 PVC | |
外护套颜色 Outer sheath color | 黑色(如有) Black, if any | |
燃烧特性 Flammability | NA | 耐火 Fire resistant, IEC60331 |
